Iscar 0.0790 in or 2.0066 mm Countersink Carbide Tialn 2 Flute End Mill

Size: 0.079″ x 0.362″ x 0.354″ x 0.724″

Description

General

The Iscar Multi-Master is a Standard length TiAlN coated countersink Carbide Countersink . It has a single end, and a shank. This mill is capable of cutting Steel 50 HRc,STAINLESS,IRON,HIGH TEMP For further size a specification data, please view the Additional Information Tab

Features and Benefits

Why use TiAlN

TiAlN is the most common coating used for machining Steel, Stainless, High Temp and Iron. This coating is good for high speed machining and is very stable in all cutting conditions. TiAlN takes rubbing better than some of its newer upgrades. This coating shows the most evident oxidization or black line behind cutting edge. This black area is a great indicator of proper use, the larger the black line the better your life will be. First choice coating for most machining.

Benefits of Carbide

Carbide is the most versatile material for cutting all materials. This should be the first choice for rigid cutting. Carbide comes in many different varieties of toughness and hardness. Round tools are limited in varsity as they are extruded. Inserts come in hundreds of combinations as they are sintered and pressed.

Industries used in

Job Shop,Energy Mfg,Mold/Die,Automotive,Aerospace,Agriculture,Medical

Shipping

Ships From: TEXAS

Additional information

Brand

Iscar

Single/Double End

Single End

Ships From

TEXAS

Model

MULTI-MASTER

Material Cut Rating

HIGH TEMP, IRON, STAINLESS, Steel 50 HRc

Flutes

2

Cutting Diameter

0.0790 in || 2.0066 mm

Shank Diameter (DCON)

0.0790 in || 2.0066 mm

Length of Cut (LB)

0.3540 in || 8.9916 mm

Overall Length (LF)

0.7240 in || 18.3896 mm

End/Corner Shape

COUNTERSINK

Tool Length

STANDARD

Material

Carbide

Cutter Style

Countersink

INCH/METRIC

INCH

Industry

AEROSPACE, AGRICULTURE, AUTOMOTIVE, ENERGY MFG, JOB SHOP, MEDICAL, MOLD/DIE

Coating

TiAlN

Chamfer Angle

40
